HP M176 - Page 69

4. Release one boss (callout 1) and remove the switch cover (callout 2).
Figure 1-68 Remove the engine controller assembly (3 of 6)
2
1
5. Disconnect all of eleven connectors (callout 1) on the engine controller PCA.
Figure 1-69 Remove the engine controller assembly (4 of 6)
1
ENWW Removal and replacement procedures 51
