Bottom
Item Component Description
(1) Battery bay Holds the battery and the subscriber identity module
(SIM) slot.
(2) Battery/service cover release latch Releases the battery from the battery bay and the service
cover from the computer.
(3) Service cover Provides access to the hard drive bay, the memory
module slot, the WLAN module, and the WWAN module
(select models only).
12 Chapter 2 External component identification
