Speakers
Description Spare part number
Speakers (include cable) 650736-001
Before removing the speakers, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 34), and then remove the following components:
{
Service cover (see
WLAN module on page 36)
{
Keyboard (see
Keyboard on page 45)
{
Top cover (see
Top cover on page 48)
Remove the speakers:
1. Release the speaker cable from the clip (1) built into the top cover.
2. Remove the speakers (2) from the top cover.
Reverse this procedure to install the speakers.
54 Chapter 4 Removal and replacement procedures
