Phillips PM2.5×11.0 captive screw
Color
Quanti
ty
Length
Thread
Head diameter
Black
1
11.0 mm
2.5 mm
4.0 mm
Where used:
One ca
ptive screw, with a C-clip, that secure
s the ha
rd drive bracket to
the base enclosure
Phillips PM2.5×11.0
captive screw
93
100
102
