7 Screw listing
This section provides specification and reference information for the screws and screw locks used in
the device. All screws listed in this section are available in the Screw Kit, spare part number 578362-001.
Phillips PM2.0×2.0 screw
Color Quantity Length Thread Head diameter
Silver 1 2.0 mm 2.0 mm 1.0 mm
Black 1 2.0 mm 2.0 mm 1.0 mm
Where used: One screw that secures the top cover to the base enclosure
80 Chapter 7 Screw listing
