HP ML150 - Power Specifications; System Specifications

Part Number
Part NumberPart Number
Part Number 402075-001
Spare Kit
Spare KitSpare Kit
Spare Kit 407730-001
Operational Input
Operational InputOperational Input
Operational Input
Voltage Range
Voltage RangeVoltage Range
Voltage Range (Vrms)
90 to 135 and 180 to 264 V ac full ranging
Frequency Range
Frequency RangeFrequency Range
Frequency Range
(Nominal) (Hz)
47 to 63 Hz
Nominal Input Voltage (Vrms)
Nominal Input Voltage (Vrms)Nominal Input Voltage (Vrms)
Nominal Input Voltage (Vrms) 100
100100
100 115
115115
115 208
208208
208 220
220220
220 230
230230
230 240
240240
240
Max Rated Output Wattage Rating 600 600 600 600 600 600
Nominal Input Current (A rms) 10 10 5 5 5 5
Max Rated Input Wattage Rating (Watts) 800 800 750 750 750 750
Max. Rated VA (Volt-Amp) 800 800 780 780 780 780
Efficiency (%) 75 77 79 80 80 80
Power Factor 0.95 0.95 0.9 0.9 0.9 0.9
Leakage Current (mA) 3.5mA 3.5mA 3.5mA 3.5mA 3.5mA 3.5mA
Maximum Inrush Current (A peak) 50 50 50 50 50 50
Maximum Inrush Current duration (mS) 3 3 3 3 3 3
System Specifications
System SpecificationsSystem Specifications
System Specifications
Power
PowerPower
Power **
HP ProLiant ML150 G3
Fully Configured
(see ** )
Fully Loaded System Input
Wattage (W)
420W
Fully Loaded System Input
Current (A rms)
5A @ 115V, 2.5A @ 230V
Fully Loaded System
Thermal (BTU- Hr)r)
1435 BTU
Fully Loaded System VA
(Volt-Amp)
420
System Leakage with all
power supplies loaded
(mA)
3.5mA
System Inrush Current with
all power supplies loaded
(A)
50A
Power cord requirements Nema 5-15P to IEC320-C13
IEC320-C13 to IEC320-C14
**Power shown is for a fully configured system consisting of:
(2) CPU
(4) double-sided DIMMs
(6) HDDs SAS/SATA
(1) CD-ROM
(0) DVD-ROM
(3) PCI-X 64 100MHz
(1) x4 PCI-E
(1) x8 PCI-E
QuickSpecs
HP ProLiant ML150 Generation 3 (G3)
HP ProLiant ML150 Generation 3 (G3)HP ProLiant ML150 Generation 3 (G3)
HP ProLiant ML150 Generation 3 (G3)
Power Specifications
DA - 12527 Worldwide — Version 26 — March 28, 2008 Page 20
