HP mt42 User Manual

1 Product description
Category Description
Product Name HP mt42 Mobile Thin Client
Processors
AMD
®
Carrizo processor:
A8 Pro-8600B 1.6 GHz (max turbo frequency 3 GHz), DDR3-2133, 2 MB L2 Cache, 15 W) with Radeon R6
graphics
Graphics Internal graphics:
AMD UMA graphics (with shared video memory)
Up to three independent displays supported with docking solution
Panel 35.6-cm (14-in), eDP 1.2 slim, full high-denition (FHD), AntiGlare (AG), SVA (1920 x 1080) display
Memory Two customer accessible memory module slots
DDR3L -12800 (1600 MHz) dual channel support
Supports up to 4 GB of system RAM (4096 MB (4096 MB×1))
Primary storage M.2 (NGFF) 2242 solid-state drive
M.2 (2242) 32 GB SATA-3
Audio and video Conexant smart amplier and ambient noise suppression
Dual-array microphone
Premium stereo speakers
Webcam (720p)
Ethernet Broadcom 5762 10/100/1000 Ethernet NIC with DASH Support
S3/S4/S5 Wake-on-LAN
Wireless WLAN
Integrated wireless local area network (WLAN) options by way of wireless module
Two WLAN antennas built into display assembly
Supports disabled Bluetooth
Intel Pro Wireless Display (WiDi Pro)
Compatible with Miracast-certied devices
Supports the following WLAN module:
●
Broadcom 43228 dual-band 802.11abgn 2x2 Wi-Fi Adapter + BT 4.0 combo adapter
WWAN
Integrated wireless wide area network (WWAN) options by way of wireless module
Two WWAN antennas built into display assembly
Supports the following WWAN module:
●
Huawei MU736 HSPA+ with GPS M.2 (NGFF)
1

HP mt42 Specifications

General

Graphics	Intel HD Graphics 520
Display	14-inch, 1920 x 1080 (Full HD)
Storage	512GB SSD
Operating System	Windows 10 Pro
Weight	1.5 kg (3.31 lbs)
Battery	3-cell, 48 Wh Li-ion
Ports	USB 3.0, USB-C, VGA, Ethernet, Headphone/microphone combo
Wireless	Wi-Fi 802.11ac, Bluetooth 4.2
Processor	Intel Core i7-6600U
Memory	8GB / 16GB DDR4
