2. Remove the 10 rubber plugs (1) and the SD card blank (2) from the bottom cover.
3. In the order indicated in the following image, remove the 10 Phillips PM2.5×5.0 screws that secure the
bottom cover to the computer.
IMPORTANT: To make sure the bottom cover installs properly, be sure to remove and replace the
screws in the order shown in the following image.
Component replacement procedures 27
