HP mt42 User Manual

2. Remove the 2 Phillips PM2.5×5.0 screws (1) that secure the system board to the computer.
3. Lift the right side of the system board up at an angle (2).
4. Pull the system board up and toward the right to remove it from the computer (3).
Reverse this procedure to install the system board.
50 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP mt42 Specifications

General

Graphics	Intel HD Graphics 520
Display	14-inch, 1920 x 1080 (Full HD)
Storage	512GB SSD
Operating System	Windows 10 Pro
Weight	1.5 kg (3.31 lbs)
Battery	3-cell, 48 Wh Li-ion
Ports	USB 3.0, USB-C, VGA, Ethernet, Headphone/microphone combo
Wireless	Wi-Fi 802.11ac, Bluetooth 4.2
Processor	Intel Core i7-6600U
Memory	8GB / 16GB DDR4
