Table 5-3 Cable connections
Connector Name Connector Color Description
PWR, P1 White Power supply, 6-pin
P2 White Power supply, 6-pin
PWRCPU, P3 White Power supply, 4-pin
PS STAT White Power supply, 6-pin
SATA PWR1, P160 Black Optical drive power connector, 4-pin
SATA PWR2, P161 Black Hard drive power connector, 4-pin
CHFAN, P9 Maroon Chassis fan
PB/LED, P5 Black Front power button/LED
CHFAN2, P11 Maroon 2nd chassis fan
FRNT_USB1, P24 Yellow Front I/O USB
FRNT_USB2, P25 Green Front I/O USB
FRONT AUD, P23 Blue Front audio
SPRK, P6 White Internal speaker
COMB, P52 Black Serial port
SATA0, P60 Dark blue 1st HDD
SATA1, P61 White 1st ODD or 2nd HDD if no HDD
present
SATA2, P62 Light blue 2nd HDD if ODD present
SATA3, P63 Orange eSATA port or extra ODD/HDD
connector
PAR, P126 Black Parallel port
MEDIA, P150 Black Media reader
46 Chapter 5 Removal and Replacement Procedures
