Table 3-1 Computer major component descriptions and part numbers
Item Component Spare part number
(1) Display panel assembly
NOTE: Display panels are only available as spare parts at a subcomponent level.
not available as a
spare part
(2) Top cover/keyboard
NOTE: For a detailed list of keyboard country codes, see Keyboard with top cover on page 62
Models without Thunderbolt:
● Dragon red legend keyboard, 1-zone lighting L98943-001
● White legend keyboard, RGB 4-zone lighting L98944-001
● White legend keyboard, RGB, per key lighting L98945-001
● Dragon red legend keyboard, 1-zone lighting, with numeric keypad L98946-001
● White legend keyboard, RGB 4-zone lighting, with numeric keypad L98947-001
Models with Thunderbolt:
● Dragon red legend keyboard, 1-zone lighting M00838-001
● White legend keyboard, RGB per key lighting M00839-001
● White legend keyboard, RGB, 4-zone lighting M00840-001
● Dragon red legend keyboard, 1-zone lighting, with numeric keypad M00841-001
● White legend keyboard, RGB 4-zone lighting, with numeric keypad M00842-001
(3) Touchpad
NOTE: The touchpad cable is available as spare part number L98730-001.
L98745-001
(4) RJ-45 door
For use in models with GeForce GTX 1660, 1660Ti, and RTX graphics cards L98959-001
For use in models with GeForce GTX 1650, 1650Ti graphics cards L99533-001
(5) IR board
NOTE: The IR board cable is available as spare part number L98726-001.
L98743-001
(6) System board (includes integrated processor and replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows 10 operating system
Intel Core i7-10750H processor and GeForce RTX 2070S, 8 GB graphics card L98756-xx1
Intel Core i7-10750H processor and GeForce RTX 2070S, 8 GB graphics card and an OLED display L98758-xx1
Intel Core i7-10750H processor and GeForce RTX 2070, 8 GB graphics card L98755-xx1
Intel Core i7-10750H processor and GeForce RTX 2070, 8 GB graphics card and an OLED display M05057-xx1
Intel Core i7-10750H processor and GeForce RTX 2060, 6 GB graphics card M00123-xx1
Intel Core i7-10750H processor and GeForce RTX 2060, 6 GB graphics card and an OLED display M00124-xx1
Intel Core i7-10750H processor and GeForce GTX 1660Ti, 6 GB graphics card L98750-xx1
18 Chapter 3 Illustrated parts catalog
