Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
(17) Battery
6 cell, 70 Wh L84392-006
3 cell, 52 Wh L84394-006
(18) Bottom cover
For use in models with GeForce GTX 1650, 1650Ti graphics cards L98724-001
For use in models with GeForce GTX 1660, 1660Ti, and RTX graphics cards L98723-001
Display assembly subcomponents
To identify the display assembly subcomponents, use this illustration and table.
Table 3-2 Display component descriptions and part numbers
Item Component Spare part number
(1) Display bezel L99532-001
20 Chapter 3 Illustrated parts catalog
