Table 3-2 Display component descriptions and part numbers
Item Component Spare part number
(1) Display bezel
NOTE: Bezel adhesive is available as spare part number L98957-001.
M00633-001
(2) Camera module (includes bezel adhesive and display back cover adhesive) L98760-001
(3) Display panel (includes bezel adhesive and display back cover adhesive)
FHD, 250 nits, 3.2 mm L99597-001
FHD, 144 Hz, 2.6 mm L99600-001
FHD, 144 Hz, at, 3.2 mm M12468-001
(4) Display/camera cable (includes bezel adhesive and display back cover adhesive) L98733-001
(5) Wireless antennas and cables L98720-001
20 Chapter 3 Illustrated parts catalog
