HP OMEN 880 - Page 12

EL-MF877-00 Page 12
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure55 Remove the FAN and inlet screws
Figure56 Remove the FG screw
Figure57 Cut the cable tie
Figure58 Disconnect the fan connector
Figure59 Remove LED holder
Figure60 Remove the PCB screws
