Required Equipment
• none
Removal Procedure
1. Exit all applications, including Windows.
2. Turn the OmniBook off and remove the battery and ac adapter.
3. Turn the OmniBook over, release the two latches on the bottom of the tray, and pull out the
tray. See below illustration.
4. Lift the Hard Disk, Flash Card, or System ROM out of the tray.
Replacement Procedure
1. Reverse the above steps to replace the Hard Disk, Flash Card, or System ROM.
2. Replace the battery and ac adapter.
3. Press reset.
Figure 7 - Removing Card Slot Tray
