59
11. To remove the Display from the Top Case, the display cable and two grounding cables must
be guided through the holes in the Top Case.
Replacement Procedure
1. Guide the display posts, display cable and two grounding cables on the Display through the
holes in the Top Case.
2. Replace the grounding eyelets over the display posts (see Figure 16). Use caution when
replacing the grounding eyelets, as they can be broken off easily. If this happens, the
assembly must be replaced.
3. Press the Display and Top Case firmly at each display post to snap the assembly in place.
4. Position the Top Case and Display Assembly over the Bottom Case and insert the two
keyboard flex cables into the zero-force insertion connectors. Ensure the connectors are
fully closed. Once the keyboard flex cables are secured in the connectors, do not
allow them to be pulled out. This will damage the cables.
