HP OmniBook 6100 - Notebook PC Service Manual

2-2 Removal and Replacement HP Omnibook 6000/6100
Table 2-2. Required Equipment
• Small Phillips screwdriver, preferably magnetized.
• Small flat-blade screwdriver.
• IC (PLCC) removal tool (similar to OK Industries EX-5).
Table 2-3. Recommended Screw Torques
Screw Thread Size Torque (cm-kgf) Torque (in-lbf)
M2 1.3 – 1.8 1.1 – 1.5
M2.5 (2–11 mm long) 3.0 – 3.5 2.6 – 3.0
M2.5 (12–19 mm long) 2.5 – 3.0 2.2 – 2.6
M3 3.0 – 3.5 2.6 – 3.0
Disassembly Flowchart
The following diagram shows the general “path” you will use in disassembling the computer to access
any particular component.
