Product Disassembly Process
Disassemble
Stand:
put the monitor on
the desk
horizontally with
soft stuff to
protect panel, then
separate stand
from monitor as
shown.
N/A
Disassemble
Bucket:
remove the bucket
screws
Cross
Screwdriver
Disassemble
Bucket:
use disassembling
tool to separate
back cover from
monitor (starting
from the
disassembiing
hole as shown)
Disassembling
Tool (Better)
Disassemble
Panel Assembly:
taking off the
LVDS cable and
lightbar cable and
keypad cable
firstly,then
N/A
