Speakers
Description Spare part number
Speaker Kit (includes left and right speakers and cable) 755738-001
Before removing the speakers, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see
Bottom cover on page 28).
5. Remove the battery (see
Battery on page 49).
Remove the speakers:
1. Disconnect the speaker cable from the system board (1).
2. Remove the four Phillips PM2.0×6.0 broadhead screws (2) that secure the speakers to the computer.
NOTE: Make note of the rubber gaskets (3) that fit around each screw. For installation, make sure the
gaskets are properly installed.
3. Remove the speakers (4).
Reverse this procedure to install the speakers.
50 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
