Display assembly
Description Spare part number
Display assembly (11.6-in [29.5-cm] HD, anti-glare, touchscreen, for use in red models without WWAN 755730-001
Display assembly, 11.6-in [29.5-cm] HD, anti-glare, touchscreen, for use in red models with WWAN 756108-001
Webcam 758848-001
Display cable 761350-001
Display enclosure for use in silver models 758845-001
Display enclosure for use in red models 758846-001
Hinge covers for use in red models 758847-001
Hinge covers for use in silver models 759503-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see
Bottom cover on page 28).
5. Remove the battery (see
Battery on page 49).
To remove the display assembly:
1. Release the wireless antenna cables from the clips (1) built into the base enclosure.
NOTE: The number of antenna cables may vary.
2. Disconnect the webcam cable (2) from the system board.
Component replacement procedures 53
