Right-side components
Item Component Function
(1) Digital Media Slot (select models only) Supports the following optional digital card formats:
●
Memory Stick (MS)
●
Memory Stick Pro (MSP)
●
MultiMediaCard (MMC)
●
Secure Digital (SD) Memory Card
●
xD-Picture Card (XD)
(2) Audio-out (headphone) jack Produces sound when connected to optional powered
stereo speakers, headphones, earbuds, a headset, or
television audio.
(3) Audio-in (microphone) jack Connects an optional computer headset microphone,
stereo array microphone, or monaural microphone.
(4) USB ports (2) Connects optional USB devices.
(5) RJ-45 (network) jack (optional) Connects a network cable.
(6) AC adapter light
●
Flashing white—The computer is in Sleep.
●
On white—The computer is connected to external
power.
●
Flashing amber—The computer is charged.
●
Off—The computer is not connected to external
power.
(7) Power connector Connects an AC adapter.
10 Chapter 2 External component identification
