Item Description Spare part number
Intel Core i3–330UM (1.2 GHz, 3M L3 cache) UMA 621560-001
Intel Core i3–330UM (1.2 GHz, 3M L3 cache) Discrete 621561-001
Intel Dual Core i5–430UM (1.2 GHz SC turbo up to 1.73GHz, 3M L3 cache)
Discrete
621562-001
Intel Core i3–380UM (1.33 GHz, 3M L3 cache) UMA 626598-001
Intel Core i3–380UM (1.33 GHz, 3M L3 cache) Discrete 626599-001
Intel Core i5–470UM (1.33 GHz SC turbo, 3M L3 cache) Discrete 626600-001
(11) Memory modules (PC3, 1066 MHz)
2GB 598856-001
1GB 598859-001
4GB 599092-001
(12) Power button board 626742–001
(13) Speakers 619454-001
(14) Hard drive cable (included in cable kit) 626734-001
(15) Power and RJ-45 connector and cable (included in cable kit)
(16) Hard drive (includes hard drive bracket and Mylar cover)
640 GB, 7200 RPM 619445-001
500 GB, 7200 RPM 619444-001
320 GB, 7200 RPM 619443-001
250 GB, 7200 RPM 619442-001
160 GB, 7200 RPM 619441-001
640 GB,INTERNAL, 7200 RPM 621046-001
SSD 160 GB 619445-001
Hard Drive Hardware Kit (not illustrated; includes hard drive bracket and hard
drive screws)
619446-001
(17) RTC battery (includes cable) 619451-001
(18) Battery 6C 62WHr 2.8Ah LI 619438-001
(19) Hinge covers 626737-001
(20) Base enclosure 619437-001
Plastics kit 619450-001
(21) Memory module compartment access cover
(22) Hard drive bay access cover
18 Chapter 3 Illustrated parts catalog
