4. Pull the WLAN and WWAN antenna cables (2) from the clip in the routing channel leading to the
display hinge (3).
CAUTION: Support the display assembly when removing the display screws in the following
steps. Failure to support the display assembly can result in damage to the assembly and other
components.
5. Remove the three Phillips PM2.5×7.0 screws (1) that secure the display assembly to the
computer.
6. Remove the hinge covers (2)
62 Chapter 4 Removal and replacement procedures
