5–60 Maintenance and Service Guide
Removal and Replacement Procedures
5.17 Modem Board
✎
The modem board cannot be removed from Compaq Presario
V4200and HP Compaq nx7220 models until after the system
board has been removed.
1. Prepare the computer for disassembly (Section 5.3)
and remove the following components:
a. Hard drive (Section 5.4)
b. Switch cover (Section 5.12)
c. Keyboard (Section 5.13)
d. Display assembly (Section 5.14)
e. Top cover (HP Pavilion dv4200 models, Section 5.15)
f. Base enclosure (Compaq Presario V4200 and HP Compaq
nx7220 models, Section 5.16)
Modem Board Spare Part Number Information
Modem board (high-speed 56kbps) 384623-001
