I/O address (hex) System function (shipping configuration)
AC - AD Programmable interrupt controller
B0 - B1 Programmable interrupt controller)
B2 - B3 Motherboard resources
B4 - B5 Programmable interrupt controller
B8 - B9 Programmable interrupt controller
BC - BD Programmable interrupt controller
C0 - DF DMA controller
F0 Numeric data processor
380 - 38E Motherboard resources
3B0 - 3BB ATI Mobility Radeon HD 5650
3B0 - 3BB Intel processor PCI Express Root Port 1 - D138
3C0 - 3DF ATI Mobility Radeon HD 5650
3C0 - 3DF Intel processor PCI Express Root Port 1 - D138
400 - 47F Motherboard resources
4D0 - 4D1 Programmable interrupt controller
500 - 57F Motherboard resources
680 - 69F Motherboard resources
800 - 80F Motherboard resources
D00 - FFFF PCI bus
164E - 164F Motherboard resources
2000 - 2FFF Intel 5 Series/3400 Series Chipset Family PCI Express Root Port 2 - 3B44
3000 - 3FFF Intel 5 Series/3400 Series Chipset Family PCI Express Root Port 2 - 3B42
4000 - 40FF ATI Mobility Radeon HD 5650
4000 - 40FF Intel Processor PCI Express Root Port 1 - D138
5000 - 501F Intel 5 Series/3400 Series Chipset Family SMBus controller - 3B30
5020 - 503F Intel 5 Series 4 Port SATA AHCI controller
5040 - 5047 Intel 5 Series 4 Port SATA AHCI controller
5048 - 504F Intel 5 Series 4 Port SATA AHCI controller
5050 - 5053 Intel 5 Series 4 Port SATA AHCI controller
5054 - 5057 Intel 5 Series 4 Port SATA AHCI controller
FFFF - FFFF Motherboard resources
FFFF - FFFF Motherboard resources
106 Chapter 6 Specifications ENWW
