Top cover
NOTE: The top cover spare part kit includes the TouchPad.
Description Spare part number
For use only with etched computer models equipped with a fingerprint reader 603684–001
For use only with black computer models not equipped with a fingerprint reader 603685–001
For use only with white computer models not equipped with a fingerprint reader 603686–001
For use only with red computer models not equipped with a fingerprint reader 603687–001
For use only with chrome computer models not equipped with a fingerprint reader 603688–001
Before removing the top cover:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first disconnecting the power cord from the AC outlet
and then disconnecting the AC adapter from the computer.
4. Remove the following components:
a.
Battery on page 43
b.
Hard drive cover on page 44
c.
Hard drive on page 45
d.
Optical drive on page 52
e.
Keyboard on page 53
To remove the top cover:
1. Turn the computer upside down, with the front toward you.
2. Remove the following screws from the bottom of the computer:
●
Three screws from the left side
●
Four screws from the right side
●
One screw from the rear
●
Two screws from the front
●
One screw from near the RTC battery
ENWW
Component replacement procedures
55
