3.
Disconnect the touchscreen cable (3) from the system board.
CAUTION: Support the display assembly when removing the following screws. Failure to
support the display assembly might result in damage to the display assembly and other computer
components.
4. Remove the three screws (1) that secure the display assembly to the computer.
5. Remove the Touchscreen display assembly (2).
6. To replace the display enclosure or any of the display assembly internal components, remove the
following:
●
Two rubber screw covers on the display bezel bottom edge (1). The display rubber screw
covers are included in the Display Rubber Kit, spare part number 603659-001.
●
Two screws (2).
ENWW
Component replacement procedures
61
