11.
Remove the display enclosure. The Touchscreen display enclosure spare part number is 603663–
001.
12. To replace the display hinges, remove the six screws (1) that secure the display hinges to the top
of the display panel.
13. Remove the three screws (2) on the side of each display hinge.
14. Remove the display hinge (3). The display hinge is available in the Display Hinge Kit, spare part
number 603644-001.
ENWW
Component replacement procedures
63
