4. Slide the hard drive tab (3) to the left, and then lift the hard drive out of the hard drive bay.
NOTE: After removing the hard drive from the computer, you must remove the hard drive
bracket to access the hard drive itself.
5. Remove the 2 screws (1) from the hard drive bracket.
6. Remove the hard drive bracket (2) from the hard drive.
7. Disconnect the hard drive cable (3) from the hard drive.
To install a hard drive, reverse this procedure.
NOTE: When installing the second hard drive, carefully insert the hard drive cable under the cable
clips before connecting the hard drive cable.
Improving performance 57
