5–4 Maintenance and Service Guide
Removal and Replacement Procedures
Section Description
# of Screws Removed
5.12 Speaker Assembly 2
5.13 Power Button Board 2
5.14 Display Assembly
Display bezel
Camera module
Display inverter
Display panel
Display hinges
Wireless antenna transceivers
Microphones
Camera cable
4
6
0
0
4
4
2
0
0
5.15 Top Cove r 14 to remove the top cover
4 to remove the top cover
support trim
5.16 Audio Board 2
5.17 Bluetooth Module 2
5.18 ExpressCard Assembly 4
5.19 USB/Power Connector Board 2
5.20 System Board 2
5.21 Fan/Heat Sink Assembly 4
5.22 Processor 1 loosened
Disassembly Sequence Chart
(Continued)
