5–52 Maintenance and Service Guide
Removal and Replacement Procedures
5.16 Audio Board
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
❏ Hard drive (Section 5.4)
❏ Optical drive (Section 5.9)
❏ Switch cover (Section 5.10)
❏ Keyboard (Section 5.11)
❏ Speaker assembly (Section 5.12)
❏ Display assembly (Section 5.14)
❏ Top cover (Section 5.15)
Audio Board Spare Part Number Information
For use with full-featured computer models (includes
infrared lens)
For use with defeatured computer models (does not include
infrared lens)
431441-001
431442-001
