HP Pavilion dv6700 - Entertainment Notebook PC User Manual

Preparing the router and the computer
Since the HP Network Assistant is a Web-based application, you must use an Ethernet cable to establish
a good Internet connection from your computer through a router and a modem to your ISP.
NOTE: If you do not have an Internet connection, you must contact an ISP and set up your service
before you can connect to the Internet.
Use the following steps to establish the wired connection:
1. If you have not already done so, connect the modem (1) (either DSL or cable modem) to the phone
or cable TV jack on the wall.
2. Connect the wireless router (purchased separately) (2) to the cable or DSL modem using an
Ethernet cable.
3. Connect the router to the computer (3) using an Ethernet cable.
4. Verify that your computer can access the Internet by opening Internet Explorer and connecting to
any Web site, such as
http://www.hp.com.
5. If you are unable to access the Internet, or receive an error message such as “Cannot Open Internet
Site,” reset the connection options:
a. From the tool bar in Internet Explorer, click Tools > Internet Options > Connections > LAN
settings.
b. In the Automatic configuration section, select the Automatically detect settings check
box, and then click OK.
c. Close and then reopen Internet Explorer.
Preparing the router and the computer 9

HP Pavilion dv6700 - Entertainment Notebook PC Specifications

General

Display Size	15.4 inches
Display Resolution	1280 x 800
Graphics	NVIDIA GeForce 8400M GS
Operating System	Windows Vista Home Premium
Wireless	802.11a/b/g/n
Audio	Altec Lansing speakers
Battery	6-cell Lithium-ion
Processor	Intel Core 2 Duo
Processor Speed	2.0 GHz
Display Type	WXGA BrightView Widescreen
RAM	Up to 4 GB DDR2
Storage	250 GB HDD
Optical Drive	DVD±RW
Bluetooth	Yes
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x RJ-45, 1 x headphone, 1 x microphone
