11. If it is necessary to remove the hinge cover, remove the four Phillips PM2.5×5.0 screws (1) that
secure the hinge cover to the display assembly, and then remove the cover (2). The hinge cover
is available using spare part number 537844-001.
12. If it is necessary to replace the webcam/microphone module, remove the Phillips PM2.0×4.0
screw (1) that secures the module to the display bezel.
13. Release the webcam/microphone module (2) as far as the webcam/microphone module cable
allows.
14. Disconnect the webcam/microphone module cable (3) and remove the webcam/microphone
module. The webcam/microphone module is available using spare part number 516312-001.
Component replacement procedures 67
