Expansion port input/output signals
The signal information in this section may be helpful if you plan to use an optional expansion product
that connects to the expansion port 3 on the computer. (The computer has only one expansion port.
The term expansion port 3 describes the type of expansion port.)
The following table identifies the input and output signals supported by the expansion port 3 on the
computer.
Feature Suport
USB 2.0 Yes
Gigabit Ethernet Yes
IEEE 1394 (4–pin port ) No
Consumer infrared (for optional remote control only) Yes
Power inputs 65-W to 90-W maximum
Composite TV Yes
S-Video TV Yes
Component TV Yes
S/PDIF audio Yes
DVI No
Headphone/speaker audio-out Yes
Microphone audio-in Yes
VGA Yes
Power button Yes
Volume control (up/down) Yes
Mute/unmute status Yes
ENWW Expansion port input/output signals 21
