HP Pavilion dv9500 - Entertainment Notebook PC Maintenance And Service Guide

Phillips PM2.5×5.0 captive screw
Color Quantity Length Thread Head width
Black 5 5.0 mm 2.5 mm 5.0 mm
Where used: 2 captive screws (secured by C-clips) that secure the memory/WLAN module
compartment cover to the computer
Where used: 3 captive screws that secure the fan/heat sink assembly to the computer
Phillips PM2.5×5.0 captive screw 131

HP Pavilion dv9500 - Entertainment Notebook PC Specifications

General

Processor	Intel Core 2 Duo
Memory	Up to 4 GB DDR2
Graphics	NVIDIA GeForce 8600M GS
Operating System	Windows Vista Home Premium
Audio	Altec Lansing speakers
HDMI Port	Yes
Chipset	Intel PM965 Express
Display Size	17.0 inch
Display Resolution	1440 x 900 (WXGA+)
Hard Drive	Up to 320 GB
Optical Drive	DVD±RW with Double Layer Support
Wireless	802.11a/b/g
Battery	6-cell Lithium-Ion
Weight	3.5 kg
USB Ports	3 x USB 2.0
