HP Pavilion dv9500 - Entertainment Notebook PC Maintenance And Service Guide

Speaker assembly
Description Spare part number
Speaker assembly 432994-001
Before removing the speaker assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 47).
5. Remove the switch cover (see
Switch cover on page 61).
6. Remove the keyboard (see
Keyboard on page 63).
Remove the speaker assembly:
1. Disconnect the speaker assembly cable (1) from the power button board.
2. Remove the wireless antenna cables and microphone cable from the clips (2) in the speaker
assembly.
3. Remove the two black Phillips PM2.5×5.0 screws (1) that secure the speaker assembly to the
computer.
66 Chapter 4 Removal and replacement procedures

HP Pavilion dv9500 - Entertainment Notebook PC Specifications

General

Processor	Intel Core 2 Duo
Memory	Up to 4 GB DDR2
Graphics	NVIDIA GeForce 8600M GS
Operating System	Windows Vista Home Premium
Audio	Altec Lansing speakers
HDMI Port	Yes
Chipset	Intel PM965 Express
Display Size	17.0 inch
Display Resolution	1440 x 900 (WXGA+)
Hard Drive	Up to 320 GB
Optical Drive	DVD±RW with Double Layer Support
Wireless	802.11a/b/g
Battery	6-cell Lithium-Ion
Weight	3.5 kg
USB Ports	3 x USB 2.0
