HP Pavilion dv9500 - Entertainment Notebook PC Maintenance And Service Guide

11. Remove the display bezel (3). Display bezels are available using the spare part numbers
447998-001 (for dual lamp display assemblies) and 447997-001 (for single lamp display
assemblies).
NOTE: See Camera module on page 48 for camera module replacement instructions. See
Display inverter on page 50 for display inverter replacement instructions.
12. If it is necessary to replace the display panel, remove the four Phillips PM2.5×8.0 screws (1) and
the two Phillips PM2.5×6.0 screws (2) that secure the display panel to the display enclosure.
13. Remove the display panel (3). Display panels are available using the following spare part
numbers:
●
447988-001 (17.0-inch, WXGA+, TFT, dual lamp, BrightView display assembly)
●
447987-001 (17.0-inch, SXGA+, TFT, single lamp, BrightView display assembly)
●
447986-001 (17.0-inch, WXGA+, TFT, single lamp, BrightView display assembly)
14. If it is necessary to replace the display hinges, remove the two Phillips PM2.0×3.0 screws (1) that
secure each display hinge to the display panel.
15. Remove the display hinges (2).
72 Chapter 4 Removal and replacement procedures

HP Pavilion dv9500 - Entertainment Notebook PC Specifications

General

Processor	Intel Core 2 Duo
Memory	Up to 4 GB DDR2
Graphics	NVIDIA GeForce 8600M GS
Operating System	Windows Vista Home Premium
Audio	Altec Lansing speakers
HDMI Port	Yes
Chipset	Intel PM965 Express
Display Size	17.0 inch
Display Resolution	1440 x 900 (WXGA+)
Hard Drive	Up to 320 GB
Optical Drive	DVD±RW with Double Layer Support
Wireless	802.11a/b/g
Battery	6-cell Lithium-Ion
Weight	3.5 kg
USB Ports	3 x USB 2.0
