Table 3-1 Computer major components and their descriptions
Item Component Spare part number
(1) Display assembly
NOTE: Spare parts for display assemblies are available only at a subcomponent level.
(2) Keyboard/top cover backlit):
For a detailed list of country codes, see Keyboard/top cover on page 58.
For use in acid green models L72597-xx1
For use in ghost white models with a backlit keyboard L72598-xx1
For use in ghost white models with a non-backlit keyboard L72599-xx1
For use in ultra violet models L72600-xx1
(3) Touchpad
NOTE: The touchpad cable is available using spare part number L72707-001.
L72709-001
(4) Hard drive
1 TB, 7200 rpm 766644-005
1 TB, 5400 rpm 762990-005
(5) Hard drive connector cable L72698-001
(6) Hard drive bracket not available as spare part
(7) Fan L72702-001
(8) Heat sink for use in models with GeForce GTX 1660 Ti graphics L81917-001
Heat sink for use in models with GeForce GTX 1650 graphics L72701-001
Heat sink for use in models with GeForce GTX 1050 graphics L72700-001
Thermal grease (not illustrated) L65268-001
(9) Power connector cable
200 W L72704-001
150 W L72703-001
(10) Power button/USB board
NOTE: The power button board cable is available using spare part number L72697-001.
For use in ghost white models L72694-001
For use in acid green models L72695-001
For use in ultra violet models L72696-001
(11) System board (includes processor and replacement thermal material):
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows 10 operating system
AMD Ryzen 7 3750H processor and 6 GB of discrete graphics memory (GeForce GTX 1660 Ti) L71932-xx1
AMD Ryzen 7 3750H processor and 4 GB of discrete graphics memory (GeForce GTX 1650) L71930-xx1
Computer major components 15
