5. To remove the wireless antenna cables and transceivers, release the wireless antenna cables from the
clips (1) built into the display enclosure, peel the transceivers from the enclosure (2), and then remove
the antenna cables and transceivers (3).
The antennas are available using spare part number 811201-001.
NOTE: Number of antennas and transceivers may vary.
6. Disconnect the cable from the touch control board (1).
Component replacement procedures 85
