Page #126 background imageLoading...
Page #126 background image
To start HP Recovery Manager from the HP Recovery partition:
1. Press f11 while the computer boots.
– or –
Press and hold f11 as you press the power button.
2. Select Troubleshoot from the boot options menu.
3. Select HP Recovery Manager, and follow the on-screen instructions.
Using HP Recovery media to recover
You can use HP Recovery media to recover the original system. This method can be used if your system
does not have an HP Recovery partition or if the hard drive is not working properly.
1. If possible, back up all personal files.
2. Insert the first HP Recovery disc you created into the optical drive on your computer or into an
optional external optical drive, and then restart the computer.
– or –
Insert the HP Recovery USB flash drive you created into a USB port on your computer, and then
restart the computer.
NOTE: If the computer does not automatically restart in HP Recovery Manager, change the
computer boot order. See
Changing the computer boot order on page 116.
3. Follow the on-screen instructions.
Changing the computer boot order
If computer does not restart in HP Recovery Manager, you can change the computer boot order, which
is the order of devices listed in BIOS where the computer looks for startup information. You can change
the selection for an optical drive or a USB flash drive.
To change the boot order:
1. Insert the HP Recovery media you created.
2. Restart the computer.
3. Press and hold esc while the computer is restarting, and then press f9 for boot options.
4. Select the optical drive or USB flash drive you want to boot from.
5. Follow the on-screen instructions.
Removing the HP Recovery partition
HP Recovery Manager software allows you to remove the HP Recovery partition to free up hard drive
space.
IMPORTANT: Removing the HP Recovery partition means you can no longer use Windows Refresh,
the Windows Remove everything and reinstall Windows option, or the HP Recovery Manager option
for minimized image recovery. Create HP Recovery media before removing the Recovery partition to
ensure you have recovery options; see
Creating HP Recovery media on page 112.
116 Chapter 10 Windows 8 – Backing up, restoring, and recovering

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Pavilion TouchSmart 15 and is the answer not in the manual?

HP Pavilion TouchSmart 15 Specifications

General IconGeneral
Processor cache1 MB
Processor cores2
Processor familyAMD A4
Processor socketSocket FP2 (µBGA-827)
Processor frequency1.9 GHz
Processor cache typeL2
Processor manufacturerAMD
Processor boost frequency2.4 GHz
Motherboard chipsetAMD A70M
Memory slots2x SO-DIMM
Internal memory4 GB
Memory form factorSO-DIMM
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)1 x 4 GB
LightScribeNo
AC adapter includedYes
HDD speed5400 RPM
SSD capacity0 GB
HDD interfaceSATA
Storage mediaHDD
Total storage capacity1000 GB
Compatible memory cardsMMC, SD, SDHC, SDXC
Number of HDDs installed1
Number of SSDs installed0
Display surfaceGloss
Display diagonal15.6 \
Touch technologyMulti-touch
Display brightness200 cd/m²
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Discrete graphics card modelNot available
Maximum graphics card memory1.98 GB
On-board graphics card modelAMD Radeon HD 7400G
On-board graphics card familyAMD Radeon HD 7000
Audio systemDolby Advanced Audio
Speakers manufacturerAltec Lansing
Front camera resolution1280 x 720 pixels
Data networkNot supported
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100Base-T(X)
Ethernet LAN data rates10, 100 Mbit/s
Charging port typeDC-in jack
Headphone connectivity3.5 mm
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Keyboard layout-
Pointing deviceTouchpad
Operating system installedWindows 8
Operating system architecture64-bit
Form factorClamshell
Product typeLaptop
Product colorBlack
Country of originChina
Battery life (max)- h
Number of battery cells4
AC adapter power65 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
Sustainability certificatesEPEAT Silver, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth259 mm
Width386 mm
Height24 mm
Weight2100 g
