3. Remove the WLAN module (3) by pulling the module away from the slot at an angle.
NOTE: If the WLAN antennas are not connected to the terminals on the WLAN module, the protective
sleeves should be installed on the antenna connectors, as shown in the following illustration.
Reverse this procedure to install the WLAN module.
Optical drive
NOTE: The optical drive spare part kit includes a bezel and bracket.
Description Spare part number
Disc ROM with SuperMulti DVD±R/RW Double-Layer Drive (includes bezel, bracket, and screws) 732075-001
48 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
