Item Component Spare part number

(4) Power button board (includes cable) 732076-001

(5) TouchPad button board (includes cable) 732078-001

(6) Power connector bracket is available with the power connector, (spare part number 732067-001)

(7) Optical drive connector cable is available with the optical drive, (spare part number 732075-001)

(8) Audio/USB port 732077-001

(9) Hard drive (does not include hard drive connector cable or hard drive rubber bracket):

1 TB, 5400 rpm, 7.0 mm/9.5 mm 676521-005

750 GB, 5400 rpm, 7.0 mm/9.5 mm 634250-005

500 GB, 5400 rpm, 7.0 mm 683802-005

500 GB, 5400 rpm, 9.5 mm 669299-005

Hard Drive Hardware Kit (not illustrated, includes hard drive rubber bracket, 2

hard drive retention brackets, and hard drive connector cable).

732071-001

(10) System board (includes replacement thermal material):

For computer models equipped with Intel UMA processors

4th generation

Intel Core i5-4200U 1.6 GHz processor (3 MB L3 cache, 15 W) for use with

FreeDOS and Ubuntu

732086-001

Intel Core i5-4200U 1.6 GHz processor (3 MB L3 cache, 15 W) for use with

Windows Standard

732086-501

Intel Core i5-4200U 1.6 GHz processor (3 MB L3 cache, 15 W) for use with

Windows Professional

732086-601

Intel Core i3-4005U 1.7 GHz processor (3 MB L3 cache, 15 W) for use with

FreeDOS and Ubuntu

732087-001

Intel Core i3-4005U 1.7 GHz processor (3 MB L3 cache, 15 W) for use with

Windows Standard

732087-501

Intel Core i3-4005U 1.7 GHz processor (3 MB L3 cache, 15 W) for use with

Windows Professional

732087-601

For computer models equipped with Intel UMA processors

3rd generation

Intel Pentium 2117U DC HM76 1.8 GHz (2 MB L3 Cache, 1600MHz DDR3, 17 W)

for use with FreeDOS and Ubuntu

737980-001

Intel Pentium 2117U DC HM76 1.8 GHz (2 MB L3 Cache, 1600MHz DDR3, 17 W)

for use with Windows Standard

737980-501

Intel Pentium 2117U DC HM76 (1.8-GHz, 2-MB L3 Cache, 1600MHz DDR3, 17 W)

for use with Windows Professional

737980-601

Intel Celeron 1007U DC HM76 1.5-GHz (2 MB L3 Cache, 1600MHz DDR3, 17 W)

for use with FreeDOS and Ubuntu.

737981-001

20 Chapter 3 Illustrated parts catalog
