Item Component Spare part number
For use only on computer models equipped with a graphics subsystem with Intel
discrete memory
732070-001
For use only on computer models equipped with a graphics subsystem with Intel
UMA memory
732069-001
Heat sink for use only on computer models equipped with a graphics subsystem with
AMD UMA memory 19 W
734448-001
Heat sink for use only on computer models equipped with a graphics subsystem with
AMD UMA memory 25 W
734449-001
Heat sink for use only on computer models equipped with a graphics subsystem with
AMD discrete memory 19 W
734450-001
Heat sink for use only on computer models equipped with a graphics subsystem with
AMD discrete memory 25 W
734451-001
(14) Power connector (includes bracket): 732067-001
(15) Hard drive connector cable is available in the hardware kit, part number 732071-001
(16) Memory modules (2, PC3L, 12800, 1600-MHz):
2 GB memory module 691739-001
4 GB memory module 691740-001
8 GB memory module PC3L 12800 1600Mhz SHARED 693374-001
8 GB memory module PC3 12800 1600Mhz SHARED 670034-001
(17) WLAN module:
Ralink RT3290LE 802.11b/g/n 1×1 WiFi and Bluetooth 4.0 Combo Adapter for use
on all computer models
690020-001
Atheros AR9485 802.11b/g/n WiFi Adapter for use on all computer models 675794-001
Realtek RTL8188EE 802.11bgn Wi-Fi Adapter for use on all computer models 709848-001
Mediatek MT7630E 802.11bgn Wi-Fi Adapter and Mediatek Bluetooth 4.0 Adapter
for use only on computer models equipped with an AMD processor
710418-001
Intel Centrino Advanced-N 6235 WLAN module for use only on computer models
in Japan
717384-001
(18) Speakers (include, speaker cables, and 4 rubber isolators) 732084-001
(19) 4 cell, 41-Wh, 2.8-Ah, Li-ion battery 728460-001
(20) Base enclosure (includes battery release latch mechanism and RJ45 cover) 732065-001
(21) Optical Drive SuperMulti DVD±R/RW Double-Layer Drive (includes bezel
and bracket)
732075-001
(22) Service door (part of the plastics kit 732079-001)
24 Chapter 3 Illustrated parts catalog

HP Pavilion TouchSmart 15 Specifications

General

Processor cache	1 MB
Processor cores	2
Processor family	AMD A4
Processor socket	Socket FP2 (µBGA-827)
Processor frequency	1.9 GHz
Processor cache type	L2
Processor manufacturer	AMD
Processor boost frequency	2.4 GHz
Motherboard chipset	AMD A70M
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
LightScribe	No
AC adapter included	Yes
HDD speed	5400 RPM
SSD capacity	0 GB
HDD interface	SATA
Storage media	HDD
Total storage capacity	1000 GB
Compatible memory cards	MMC, SD, SDHC, SDXC
Number of HDDs installed	1
Number of SSDs installed	0
Display surface	Gloss
Display diagonal	15.6 \
Touch technology	Multi-touch
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
Maximum graphics card memory	1.98 GB
On-board graphics card model	AMD Radeon HD 7400G
On-board graphics card family	AMD Radeon HD 7000
Audio system	Dolby Advanced Audio
Speakers manufacturer	Altec Lansing
Front camera resolution	1280 x 720 pixels
Data network	Not supported
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Keyboard layout	-
Pointing device	Touchpad
Operating system installed	Windows 8
Operating system architecture	64-bit
Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Battery life (max)	- h
Number of battery cells	4
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Sustainability certificates	EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	259 mm
Width	386 mm
Height	24 mm
Weight	2100 g
