HP Pavilion TouchSmart 15 User Manual

Description Spare part number
Painted island style white finish for use in the United Kingdom 720597-031
Painted island style white finish for use in Greece 720597-041
Painted island style white finish for use in France 720597-051
Painted island style white finish for use in Italy 720597-061
Painted island style white finish for use in Spain 720597-071
Painted island style white finish for use in Portugal 720597-131
Painted island style white finish for use in Turkey 720597-141
Painted island style white finish for use in Greece 720597-151
Painted island style white finish for use in Saudi Arabia 720597-171
Painted island style white finish for use in Hungary 720597-211
Painted island style white finish for use in Russia 720597-251
Painted island style white finish for use in Bulgaria 720597-261
Painted island style white finish for use in Romania 720597-271
Painted island style white finish for use in Thailand 720597-281
Painted island style white finish for use in Japan 720597-291
Painted island style white finish for use in Belgium 720597-A41
Painted island style white finish for use in Taiwan 720597-AB1
Painted island style white finish for use in South Korea 720597-AD1
Painted island style white finish for International use 720597-B31
Painted island style white finish for use in Slovenia 720597-BA1
Painted island style white finish for use in Israel 720597-BB1
Painted island style white finish for use in Switzerland 720597-BG1
Painted island style white finish for use in Israel 720597-DB1
Painted island style white finish for use in Nordic regions 720597-DH1
Painted island style white finish for use in the Czech Republic and Slovakia 720597-FL1
Painted island style white finish for use in Northwest Africa 720597-FP1
Before removing the keyboard, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 43).
56 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP Pavilion TouchSmart 15 Specifications

General

Processor cache	1 MB
Processor cores	2
Processor family	AMD A4
Processor socket	Socket FP2 (µBGA-827)
Processor frequency	1.9 GHz
Processor cache type	L2
Processor manufacturer	AMD
Processor boost frequency	2.4 GHz
Motherboard chipset	AMD A70M
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
LightScribe	No
AC adapter included	Yes
HDD speed	5400 RPM
SSD capacity	0 GB
HDD interface	SATA
Storage media	HDD
Total storage capacity	1000 GB
Compatible memory cards	MMC, SD, SDHC, SDXC
Number of HDDs installed	1
Number of SSDs installed	0
Display surface	Gloss
Display diagonal	15.6 \
Touch technology	Multi-touch
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
Maximum graphics card memory	1.98 GB
On-board graphics card model	AMD Radeon HD 7400G
On-board graphics card family	AMD Radeon HD 7000
Audio system	Dolby Advanced Audio
Speakers manufacturer	Altec Lansing
Front camera resolution	1280 x 720 pixels
Data network	Not supported
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Keyboard layout	-
Pointing device	Touchpad
Operating system installed	Windows 8
Operating system architecture	64-bit
Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Battery life (max)	- h
Number of battery cells	4
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Sustainability certificates	EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	259 mm
Width	386 mm
Height	24 mm
Weight	2100 g
