HP Pavilion TouchSmart 15 User Manual

Description Spare part number
Intel Core i7-4500U (1.8 GHz DC BGA 15W) for use with FreeDOS and Ubuntu. 737986-001
Intel Core i7-4500U (1.8 GHz DC BGA 15W) for use with Windows Standard. 737986-501
Intel Core i7-4500U (1.8 GHz DC BGA 15W) for use with Windows Professional. 737986-601
Intel Core i5-4200U 740M 2 GB (1.6 GHz DC BGA 15W) for use with FreeDOS and Ubuntu. 736377-001
Intel Core i5-4200U 740M 2 GB (1.6 GHz DC BGA 15W) for use with Windows Standard. 736377-501
Intel Core i5-4200U 740M 2 GB (1.6 GHz DC BGA 15W) for use with Windows Professional. 736377-601
Intel Core i5-4200U 8670M 1 GB (1.6 GHz DC BGA 15W) for use with FreeDOS and Ubuntu. 737669-001
Intel Core i5-4200U 8670M 1 GB (1.6 GHz DC BGA 15W) for use with Windows Standard. 737669-501
Intel Core i5-4200U 8670M 1 GB (1.6 GHz DC BGA 15W) for use with Windows Professional. 737669-601
Intel Core i3-4005U 8670M 1 GB (1.7 GHz DC BGA 15W) for use with FreeDOS and Ubuntu. 732089-001
Intel Core i3-4005U 8670M 1 GB (1.7 GHz DC BGA 15W) for use with Windows Standard 732089-501
Intel Core i3-4005U 8670M 1 GB (1.7 GHz DC BGA 15W) for use with Windows Professional. 732089-601
For computer models equipped with Intel Discrete processors.
3rd generation
Intel Core i3-3217U DC 8670M 1 GB HM76 (1.8 GHz, L3 Cache, 1600MHz DDR3, 17W) for
use with FreeDOS and Ubuntu.
737984-001
Intel Core i3-3217U DC 8670M 1 GB HM76 (1.8 GHz, L3 Cache, 1600MHz DDR3, 17W) for
use with Windows Standard.
737984-501
Intel Core i3-3217U DC 8670M 1 GB HM76 (1.8 GHz, L3 Cache, 1600MHz DDR3, 17W) for
use with Windows Professional.
737984-601
Intel Core i3-3217U DC 8670M 2 GB HM76 (1.8 GHz, L3 Cache, 1600MHz DDR3, 17W) for
use with FreeDOS and Ubuntu.
737985-001
Intel Core i3-3217U DC 8670M 2 GB HM76 (1.8 GHz, L3 Cache, 1600MHz DDR3, 17W) for
use with Windows Standard.
737985-501
Intel Core i3-3217U DC 8670M 2 GB HM76 (1.8 GHz, L3 Cache, 1600MHz DDR3, 17W) for
use with Windows Professional.
737985-601
Intel Pentium 2117U DC 8670M 1 GB HM76 (1.8 GHz, L3 Cache, 1600MHz DDR3, 17W) for
use with FreeDOS and Ubuntu.
737983-001
Intel Pentium 2117U DC 8670M 1 GB HM76 (1.8 GHz, L3 Cache, 1600MHz DDR3, 17W) for
use with Windows Standard.
737983-501
Intel Pentium 2117U DC 8670M 1 GB HM76 (1.8 GHz, L3 Cache, 1600MHz DDR3, 17W) for
use with Windows Professional.
737983-601
For computer models equipped with AMD UMA processors.
AMD A4-5000 (1.5 GHz, 2 MB L2, 1600MHz DDR3L, Quad 15W) for use with FreeDOS and
Ubuntu.
734826-001
AMD A4-5000 (1.5 GHz, 2 MB L2, 1600MHz DDR3L, Quad 15W) for use with Windows
Standard.
734826-501
76 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP Pavilion TouchSmart 15 Specifications

General

Processor cache	1 MB
Processor cores	2
Processor family	AMD A4
Processor socket	Socket FP2 (µBGA-827)
Processor frequency	1.9 GHz
Processor cache type	L2
Processor manufacturer	AMD
Processor boost frequency	2.4 GHz
Motherboard chipset	AMD A70M
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
LightScribe	No
AC adapter included	Yes
HDD speed	5400 RPM
SSD capacity	0 GB
HDD interface	SATA
Storage media	HDD
Total storage capacity	1000 GB
Compatible memory cards	MMC, SD, SDHC, SDXC
Number of HDDs installed	1
Number of SSDs installed	0
Display surface	Gloss
Display diagonal	15.6 \
Touch technology	Multi-touch
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
Maximum graphics card memory	1.98 GB
On-board graphics card model	AMD Radeon HD 7400G
On-board graphics card family	AMD Radeon HD 7000
Audio system	Dolby Advanced Audio
Speakers manufacturer	Altec Lansing
Front camera resolution	1280 x 720 pixels
Data network	Not supported
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Keyboard layout	-
Pointing device	Touchpad
Operating system installed	Windows 8
Operating system architecture	64-bit
Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Battery life (max)	- h
Number of battery cells	4
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Sustainability certificates	EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	259 mm
Width	386 mm
Height	24 mm
Weight	2100 g
