1–14 Hardware and Software Guide
Component ID
Bottom Components
Bays and Vents
Component Description
1
Battery bay Holds a battery pack.*
2
Exhaust vents (5) Provide airflow to cool internal
components.
Ä
To prevent overheating, do not
obstruct vents. Do not allow a hard
surface, such as a printer, or a soft
surface, such as pillows or thick
rugs or clothing, to block airflow.
3
Hard drive bay Holds the primary hard drive.
4
Battery pack release latch Releases a battery pack from the
battery bay.
*Battery packs vary by notebook model.
