HP Photosmart C5100 All-in-One Series

Label Description
1 Color graphics display (also referred to as
the display)
2 Control panel
3 Output tray (currently shown in the up
position)
4 Paper-width guide for the main input tray
5 Main input tray (also referred to as the input
tray)
6 Paper tray extender (also referred to as the
tray extender)
7 Paper-width and paper-length guides for the
photo tray
8 Photo tray
9 Paper-length guide for the main input tray
10 Ink cartridge door
11 Memory card slots
12 Glass
13 Lid backing
Label Description
1 Ethernet port
2 USB port
3 Power connection
*
4 Rear door
* Use only with the power adapter supplied by HP.
Basics Guide 3
HP All-in-One overview
