4-Cell (44 WHr) Lithium-
Ion battery
Dimensions
(H x W x L)
0.86 x 1.4 x 8.0 in (2.18 x 3.56 x 27.72 cm)
Weight
(max)
<0.551 lb (250 g)
Cells/Type
4-cell Lithium-Ion
Energy
Voltage
14.8V DC
Amp-hour capacity
2850mAh
Watt-hour Capacity
44 WHr
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (-10° to 60° C)
Non-operating
-4° to 140° F (-20° to 60° C)
Battery Re-Charge Time
System in OFF or Standby
Mode
2.5 hours
System ON
3 to 5 hours (depending on system power
consumption)
Fuel Gauge LED
No
Warranty
1 year
Optional Travel Battery
Available
No
ENVIRONMENTAL DATA
Eco-Label Certifications
This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:
US ENERGY STAR®
IT ECO declaration
EPEAT® - <Gold> where HP registers commercial notebook products. See
http://www.epeat.net
for
registration status in your country
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the Commercial
Notebook model is based on a "Typically Configured Notebook"
Energy Consumption
115 VAC 230 VAC 100 VAC
Normal Operation
6.02 W 6.10 W 5.91 W
Sleep (Energy Star low
power mode)
0.52 W 0.60 W 0.51 W
Off
0.30 W 0.37 W 0.28 W
Heat Dissipation
*
115 VAC 230 VAC 100 VAC
Normal Operation
21 BTU/hr 21 BTU/hr 20 BTU/hr
Sleep
2 BTU/hr 2 BTU/hr 2 BTU/hr
Off
1 BTU/hr 1 BTU/hr 1 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one
hour.
QuickSpecs
HP ProBook 430 Notebook
Technical Specifications
DA - 14589 Worldwide — Version 6 — August 26, 2013
Page 29
