3–4 Maintenance and Service Guide
Illustrated parts catalog
(4) Keyboard
(continued)
:
■ For use in Iceland 577205-DD1
■ For use in Israel 577205-BB1
■ For use in Italy 577205-061
■ For use in Japan 577205-291
■ For use in Latin America 577205-161
■ For use in the Netherlands 577205-B31
■ For use in Norway 577205-091
■ For use in Portugal 577205-131
■ For use in Russia 577205-251
■ For use in Saudi Arabia 577205-171
■ For use in Slovakia 577205-231
■ For use in Slovenia 577205-BA1
■ For use in South Korea 577205-AD1
■ For use in Spain 577205-071
■ For use in Sweden and Finland 577205-B71
■ For use in Switzerland 577205-BG1
■ For use in Taiwan 577205-AB1
■ For use in Thailand 577205-281
■ For use in Turkey 577205-141
■ For use in the United Kingdom 577205-031
■ For use in the United States 577205-001
(5a) Palm rest (included with top cover spare part kit)
(5b) Top cover (includes palm rest, TouchPad button board and cable, and TouchPad board and cable):
■ For use only on computer models equipped with fingerprint reader in black trim (includes
fingerprint reader board and cable)
577216-001
■ For use only on computer models equipped with fingerprint reader in red trim (includes
fingerprint reader board and cable)
577218-001
■ For use only on computer models not equipped with fingerprint reader in black trim 577217-001
■ For use only on computer models not equipped with fingerprint reader in red trim 577219-001
(6) Bluetooth module 537921-001
✎
The Bluetooth module spare part kit does not include a Bluetooth module cable. The Bluetooth module cable is
included in the Cable Kit, spare part number 577214-001.
Plastics Kit, includes: 577211-001
(7a) ExpressCard slot bezel
(7b) SD Card Reader slot bezel
(7c) Hard drive cover
(7d) Memory/wireless module compartment cover
✎
See “Plastics Kit” on page 3-12 for more Plastics Kit spare part information.
(Continued)
Item Description Spare part number
