3–6 Maintenance and Service Guide
Illustrated parts catalog
(14) Processor (includes replacement thermal material):
Intel Core2 Duo processors:
■ T9600 2.80-GHz processor, 6-MB L2 cache, 1066-MHz FSB 507955-002
■ P8700 2.53-GHz processor, 3-MB L2 cache, 1066-MHz FSB 507960-001
■ P7570 2.26-GHz processor, 3-MB L2 cache, 1066-MHz FSB 572930-001
■ P7370 2.00-GHz processor, 3-MB L2 cache, 1066-MHz FSB 507966-001
Intel Core Duo processors:
■ T6570 2.10-GHz processor, 2-MB L2 cache, 800-MHz FSB (not available in Japan) 513598-001
■ T5870 2.00-GHz processor, 2-MB L2 cache, 800-MHz FSB (not available in Japan) 535835-001
■ T4200 2.00-GHz processor, 1-MB L2 cache, 800-MHz FSB 513599-001
■ T3100 1.90-GHz processor, 1-MB L2 cache, 800-MHz FSB 572925-001
■ T3000 1.80-GHz processor, 1-MB L2 cache, 800-MHz FSB 572926-001
(15) Fan (includes replacement thermal material) 577206-001
(16) Heat sink (includes replacement thermal material):
■ For use only on computer models equipped with a graphics subsystem with
discrete memory
577227-001
■ For use only on computer models equipped with a graphics subsystem with
UMA memory
577226-001
(17) Optical drive (includes bezel and bracket):
■ Blu-ray ROM DVD±R/RW SuperMulti Double-Layer Drive with LightScribe 577202-001
■ DVD±RW and CD-RW SuperMulti Double-Layer Drive with LightScribe 577204-001
■ DVD-ROM Drive 577203-001
(18) Base enclosure (includes 5 rubber feet) 577209-001
Rubber Feet Kit (not illustrated, includes 5 rubber feet and 8 display bezel screw covers) 577212-001
(19) Battery:
■ 8-cell, 2.55-Ah (73-Wh) Li-ion battery 579320-001
■ 6-cell, 2.20-Ah (37-Wh) Li-ion battery 579319-001
(20) Hard drive (includes hard drive connector and hard drive bracket):
■ 500-GB, 7200-rpm 579213-001
■ 500-GB, 5400-rpm 577201-001
■ 320-GB, 7200-rpm 579212-001
■ 320-GB, 5400-rpm 577200-001
■ 250-GB, 7200-rpm 577199-001
■ 160-GB, 7200-rpm 577198-001
(21) Memory modules (1333-MHz, DDR2):
■ 2048-MB 577197-001
■ 1024-MB 577196-001
(Continued)
